If you are looking
for a unit to show you precise depth down to 2 ft and temperature to 0.02
of a degree, then the RD30 is the answer. Simply connect the RD30 to our
optional new Furuno Smart
Sensor and you are ready to go! The new Furuno Smart Sensor is an ingeniously
engineered depth sensor, entirely encased within its own transducer housing.
The Smart Sensor connects directly to the RD30 display, via the NMEA data
port, without requiring any additional processor or junction box. Power is
supplied to the Smart Sensor from the connected display. The Smart Sensor
operates at 235kHz. This frequency was chosen for its excellent ability to
provide solid performance at both high speeds and in very shallow depths.
Additionally, the 235kHz frequency will not interfere with other Furuno echo
sounding equipment, including any products running at 200kHz.
These versatile products can also be added to any NavNet® system,
providing numerous NMEA data display modes, including: Depth, Temperature,
Wind Data, Speed, Bearing, Course, Position, etc.
|
| |
|
Standard
Features
- Versatile, Multi-Function, NMEA0183 Display and Data
Repeater
- Rugged, Waterproof Housing with 4.5” Mono LCD
- Two independent NMEA0183 Input and Output Ports
- Programmable data-combiner, for mixture of NMEA0183
input port data to output port
- Up to 8 NMEA Data parameters can be combined onto
either or both NMEA0183 Output Ports
- Five Fully Programmable User Display Modes with Text,
Graphic, and Graphing Capabilities
- Compatibility and Capability to Mix NMEA0183 Sources
from any NMEA0183 device
- Simultaneous Alarm Setting Capabilities for the following
parameters:
Temp (.01)/Depth/Speed/Arrival/Anchor/XTE/Trip/Odometer/Timer and Countdown
Timer
- Multiple Displays can be “Daisy-Chained” using a
maximum of three displays in a chain
- Power to the displays can be controlled from a NavNet
display or the first RD-30 in the chain
- Programmable “Offsets” are provided from Depth, Temp,
Speed, Time and Wind Information
- “Built-In” LORAN TD converter
- Resettable Trip and Odometer Functions
- Optional Smart Sensor connects to and is powered
by the RD30 display
- Cable Extensions will not affect temperature sensing
or depth measurements.
- Spare NMEA0183 Input Port allows RD30/Smart Sensor
System to be utilized simultaneously
as a Remote Navigation Data Repeater
- Optional Smart Sensor features 235kHz Digital Echo
Sounder and Standard/High Precision Temp Sensor
- Unique 235kHz provides superior High Speed and Shallow
Water performance
- Smart Sensor Performance - Approximately 2.5 feet
min. - 330 feet max (.8 meters-100 meters)
at speeds up to 50 knots depending on installation and placement
|
| |
|
Retail Price: $395.00 |
|
|
